224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯来发电用打着机燃料城市发展性好: 好的燃料有效把控模式，别具一格 的STC、ESTC 分级分类有效把控模式，个性化方案的汽缸边侧燃燒室，低压喷涌燃料，宽裕雾化吸入，燃燒宽裕。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电量用打火机瞬态特点比较好: 终极的打火机局部设计，协助康明斯独一无二的EFC装置，抑制gps精性高，运行时刻快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯风能发电用起驱动力升电机功率高: 综合方案紧凑型轿车.看上去摆置科学合理，开机运行稳步。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷手机型号 QSNT. QSK19. QSK38. QSK50满足了中国国非旅程其次价段及美国Tier2. Tier 3排放标准法律法规的要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件必得性好， 打着机作业及定期维护清洗便捷，成本费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

功效范围内 Power Range   224-310KW型号规格 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观简约时尚的尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效果 Dry Weight   940kg

224-310KW康明斯电站用打着机的特性：占地小， 再压缩比低， 喷淋喷嘴大气电加热，最易重启，中移动车载电子24v电源的好选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

起倾向形号	选用电功率(kW)Prime Power	预备热效率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
